| Optical | |
|---|---|
| Compliance | ICAO Annex 14, Vol 1, July 2018 / FAA AC150/5345-46E, L-861, L-861E |
| Configuration | Solar LED Runway Edge / Threshold Light |
| Output | Visible / IR |
| Visible LED Light | Red, Green, White, Yellow, Blue, Bi-directional Combinations |
| Peak Luminous Intensity | LED / Lens: 700 candela |
| LED Life Expectancy | Long Life – Up to 100,000 hours |
| Electrical | |
| Battery | 12VDC, 24Ah. Optional Mil Spec Batteries available |
| Solar Panel | 28 Watt (4 x 7 Watt by side) |
| Autonomy | 112 hours max. intensity / 400 hours min. intensity (without charging) |
| Alternate Power | Optional Hybrid AC |
| Standard Operating Temperature | –40°C to 55°C (-40°F to 131°F) |
| Mechanical | |
| Mounting | 4 hole 200mm bolt pattern |
| Body Material | Composite Polymer – Grivory |
| Lens Material | Multi-LED optic |
| Lens Design | 78.4cm x 33.7cm x 11.5cm (30.875” x 13.25” x 4.4”) |
| Height (mm/inches) | 503mm / 20″ |
| Width (mm/inches) | 234mm / 9.2″ |
| Weight (kg/lbs) | 14kg / 30.85lbs |
Solar Runway Light
Solar Runway Light
Complies with:
- FAA L860 & L861 photometrics
- ICAO Annex 14 non-precision / non-instrument
- UFC 3-535-01
- STANAG 3534 Type A & B
The Solar Runway Light is a next-generation, self-contained solar light specifically designed to survive the harshest environments with minimal ongoing maintenance. It is a robust, completely self-contained LED solar aviation light designed for a range of aviation applications including permanent approach, runway edge, threshold, helipad aviation lighting. This fully functioning light can be controlled from the tower with no costly cabling or trenching required when fitted with RF.
The Solar Runway Light includes the latest solar technology including active MPPT (maximum power point tracking – maximising the power extracted from the solar panels) and enhanced optics for improved performance and efficiency with IR available.
Features
- Solar-powered, Self-Contained
- Available in a Compact or Standard model
- Updated Switch and External Interface Port (Charge Port)
- Optional RF Control via AvMesh® RF Network
- Internal antenna removing risk of damaged presented by external devices
- Multiple operating modes – programmable light groups, 3-step intensity adjustment, switchable between visual and IR for tactical operations (where fitted)
Applications
- Runway Edge
- Runway Caution
- Threshold
- REIL
- Simple Approach & Sequenced Approach
- Helipad
- Obstruction
…
